Rigid Box making machine
It is used to make hardcovers, notebook covers, desk calendars, hanging calendars, book-type boxes, files and regular covers etc.
The machine comprises four parts: main motor, auto feeder, and electric equipment. The motor’s main transmission is by bend shaft structure driving the platen running up and down, plus the pressure adjusting structure, coordinate to finish die cutting job. It can automatically feed and glue paper, delivery and position cardboard, and fold four sides in one process; there are features of accurate and quick positioning, and beautiful finished products etc.
| Model | KL1300ASD |
| Cardboard size | Max.W1100mmxL1260mm Min. W620mm×L620mm |
| Cardboard thickness | 1-4mm |
| Stacking height | 1300mm |
| Maximum size of receiving pile | 1300mm |
| First cutting size | X140-520mm Y620-1100mm |
| Second cutting size | X140-520mm Y55-1100mm |
| Speed | ≤60m/min |
| Power | 16.2kw/380v 3phase |
| Air supply | 7L/min 0.6Mpa |
| Machine weight | 5500kg |
| Machine dimension | L10160xW4750xH1930mm |
*All parameters are subjected to our final confirmation before order.
