Rigid Box making machine
The RB380 can produce various types of boxes, including gift boxes, shoe boxes, cosmetic boxes, etc., making it suitable for use in many different industries.
Capable of producing 50 high-quality boxes per minute, the RB380 is the ideal solution for high-volume box production. The machine is equipped with dual workstations that can run production simultaneously, making the production process more efficient and increasing output. Advanced technology and automated manufacturing processes ensure precise cutting, folding and gluing of cardboard, resulting in stable, high-quality carton production with high efficiency and energy saving.
| Model | RB380 |
| Box Size [WxL] | Min.50x60mm Max.260x380mm |
| Paper Size [AxB] | Min.70x120mm Max.480x630mm |
| Box Height[H] | 10-120mm |
| Turn in Depth[R] | 10-100mm |
| Cardboard Thickness[T] | 0.8-3mm |
| Paper Thickness | 80-300g/m2 |
| Paper Stacking Height | 650mm |
| Precision | ±0.1mm |
| Speed | <50pcs/min |
| Motor Power | 28kw/380v 3phase |
| Electric Heating Power | 6kw |
| Air Supply | 50L/min 0.6Mpa |
| Machine Dimension | L6300xW8000xH3300mm |
| Machine Weight | 5500kg |
*All parameters are subjected to our final confirmation before order.
